The structure of surfactants is quite straightforward: one end is hydrophilic (water‑loving) and the other lipophilic (oil‑loving). Each end binds to its respective counterpart, water and oil. The surfactant molecules assemble at the oil‑water interface, and that forms the basic setup. Emulsification is only one of the functions of surfactants, yet it is the most widely‑used function in our industry. It is mainly applied for blending water‑borne oils, such as emulsified oils and water‑containing fire‑resistant hydraulic fluids. In fact, however, emulsifiers find extremely broad applications in daily‑life products including milk, ice‑cream and shampoo, all of which contain emulsifiers to varying degrees.
Owing to this simple molecular architecture, numerous substances exhibit emulsifying properties, which makes emulsifier selection quite nuanced. It can be stated that without a sound understanding of emulsifiers, one can hardly develop qualified water‑based lubricant products. It is common knowledge that oil and water are immiscible. Emulsifiers are therefore required to bring them together. In this forced combination, one phase will transform into tiny liquid droplets while the other liquid fully envelops these droplets. This gives rise to the concepts of continuous phase and dispersed phase: one phase is broken into discontinuous droplets and the other forms an uninterrupted continuous medium. Macroscopically, this produces either water‑in‑oil (W/O) or oil‑in‑water (O/W) emulsions. That covers the core principles of emulsifiers.
When an emulsifier is introduced into an immiscible oil‑water system, new dispersion conditions are created to mix the two phases. This is not true dissolution in the sense of salt dissolving in water. Instead, one phase is homogeneously dispersed as fine droplets within the other phase. If external conditions change, oil and water will separate again, indicating poor emulsification or insufficient emulsion stability. Certain additives can disrupt the oil‑water equilibrium and trigger complete phase separation; such substances act counter to emulsifiers and are known as demulsifiers.
An emulsion is essentially a dispersion system. Due to dispersed‑phase droplets and differences in refractive index between phases, incident light undergoes reflection, scattering and transmission at droplet surfaces. Typical emulsion droplet sizes range from 0.1 μm to 10 μm, while visible‑light wavelengths fall between 0.4 μm and 0.6 μm. Strong reflection occurs, giving emulsions their characteristic milky‑white appearance. When droplet diameters range from 0.05 μm to 0.1 μm (slightly smaller than visible‑light wavelengths), light scattering takes place and the system appears translucent. At droplet sizes below 0.05 μm (far smaller than visible‑light wavelengths), light transmission dominates and the system becomes transparent. Systems with droplet sizes below 0.1 μm that appear translucent or transparent are defined as microemulsions, whose properties differ substantially from conventional macroemulsions. A microemulsion is still an emulsion, merely with much finer dispersed‑phase droplets. Its formation requires not only emulsifiers but also co‑emulsifiers. This demonstrates that emulsification‑driven “dissolution” essentially comes down to controlling the particle size of the dispersed phase.
Emulsifier performance hinges on a delicate balance. Its hydrophilic and lipophilic capacities constitute a seesaw effect. For instance, low‑carbon alcohols exhibit strong hydrophilicity and dissolve in water with negligible oil affinity. Conversely, excessively lipophilic substances fail to interact with water and display oil‑soluble behavior. Even though many substances bear both hydrophilic and lipophilic moieties, they cannot be classified as surfactants. If a substance is overwhelmingly hydrophilic or lipophilic, it is merely a surface‑active substance, like some of the additives mentioned above. A measurable metric for hydrophilic‑lipophilic strength is therefore needed, namely the well‑known Hydrophile‑Lipophile‑Balance (HLB) value.
The HLB value offers valuable guidance for practical emulsification, alongside various empirical techniques, which are documented in literature and will not be elaborated here. Emulsifying oil with emulsifiers is not intrinsically difficult. Optimal emulsifier types, dosages and stability conditions can be determined experimentally through trial‑and‑error. Hence emulsifier development relies heavily on experimental work. Many micro‑level mechanisms of surfactant behavior remain incompletely elucidated by researchers to this day. Beyond emulsification, surfactants deliver wetting, cleaning, detergency, spreading, solubilization and other functions. For our industry, experimental screening is a pragmatic approach, as true knowledge comes from practice. Several empirical rules have been established experimentally: blended emulsifiers outperform single emulsifiers, and combinations of anionic and non‑ionic surfactants produce favorable synergistic effects.
Despite the apparent simplicity of emulsifier theory, practical application proves complex. Using emulsifiers alone can often be resolved via experimentation, yet many subsequently‑added additives possess surface‑active properties. These interfere with emulsifier performance and alter the effective HLB of the system. A typical example is corrosion inhibitors in emulsions. These highly polar surface‑active ingredients are incorporated for rust prevention but may destabilize the oil‑water emulsion balance and must be accounted for during emulsifier selection. Formulating blends of multiple emulsifier types can reduce dosage and cost while enhancing emulsion stability. However, questions regarding how to combine different emulsifiers and their blending mechanisms drastically raise formulation complexity. A persistent misconception claims anionic and cationic emulsifiers cannot be blended. In reality, anionic‑cationic surfactant blends are widely reported in surfactant science, though they are seldom adopted within our sector. Calcium and magnesium ions present in hard water may also disrupt emulsion interfacial films and deactivate emulsifiers. Calcium ions are particularly problematic: many surfactant emulsifiers react with calcium to form water‑insoluble calcium soaps that precipitate out of the system. This topic will be discussed in the next chapter.
Accordingly, seemingly simple emulsifiers become highly complicated once other components are introduced. Producing a finished emulsion is not hard; the real challenge lies in maintaining stability under diverse service conditions, keeping oil and water permanently combined.
Performance requirements for emulsifiers:
Hard-water resistance
This parameter characterizes an emulsifier’s tolerance to hard water. Conventional anionic surfactants generally perform poorly in this respect, so non‑ionic surfactants are gradually replacing them. That said, anionic surfactants retain their unique merits.
Foaming tendency
Many traditional linear anionic surfactants generate abundant foam, fostering the mistaken belief that higher foam volume equates to superior detergency. Foam is primarily induced by surfactants. In our lubricant‑related industry, minimal foaming is almost always desirable. Unfortunately, numerous emulsifiers exhibit high foaming capacity. Formulators must therefore select suitable emulsifier grades to suppress foam formation, which explains the growing demand for so‑called low‑foam emulsifiers.
Biological stability
Biological stability represents another critical performance index for emulsifiers. If an emulsifier is susceptible to bacterial degradation during long‑term service, subsequent disposal of the corresponding cutting fluid becomes extremely problematic. Environmental‑protection regulations exert decisive influence over emulsifier selection and govern the whole industry.
Emulsifiers are categorized into anionic, cationic, amphoteric, non‑ionic and other families, all corresponding to distinct chemical substances familiar to fine‑chemistry specialists. This text will not delve into detailed popularized descriptions of each category. In our industry, anionic and non‑ionic emulsifiers predominate in terms of consumption and product diversity. Within each category exist multiple molecular structures with divergent emulsifying characteristics, each with respective strengths and weaknesses. They are frequently blended to reduce usage dosage and improve emulsion stability.
There are no absolute fixed rules for emulsifier formulation. Variables include differences in base‑oil to‑be‑emulsified, emulsifier blending ratios, service‑environment conditions, special customer specifications, and interactive effects from other additives. Nevertheless, experimentation provides a practical solution. Emulsification tests are relatively easy to carry out. Even without theoretical background, one can arrive at workable formulations through repeated trials, albeit at the cost of time. Relevant surfactant‑science theories, which accelerate development, are well‑documented in existing literature and fully adequate for addressing emulsification challenges encountered within our industry.
